Ceramic foam filter
|
|
|
|||
|
|
|
Description:
The product, adopted good portiforium foam and high purity ceramic , effectively removes non-metal solid mixture from aluminum and aluminum alloy t. Advantage : even aperture, high porosity, proper sinter, high strength of anti-flexing and anti-compression, effective filtering .It is widely applied to the aluminum filter equipment of continuous casting, half-continuous casting, gravity casting, and low pressure casting. Ceramic foam filters are different from aperture specifications from 10 to 45ppi, with different sizes and shapes. Besides the general specification ,we can offer the product according to the customers requirement
Specifications:
| Thickness mm |
Aperture PPi |
Volume intensity g/cm3 |
Tortuous intensity in normal temperature N/cm2 |
Pressure resistance intensity in normal temperature N/cm2 |
Pressure resistance intensity in high temperature N/cm2 |
Refractory temperature |
Air discharging capability cm3/g |
Porosity % |
| 15-100 | 10-45 | 0.35-0.45 | ≥38 | ≥80 | ≥45 | ≥1800 | ≤5 | ≥85 |
Form 25ppi capability of typical pouring of ceramic foam filter
| Specification mm |
Area M2 | Maximum metal volume of pouring (kg/min) |
Optimum volume of pouring (kg/min) |
Typical capacity of filtering (T) |
| 178X178X50 | 0.0213 | 57.00 | 25-45 | 4.2 |
| 229X229X50 | 0.0387 | 118.00 | 35-102 | 6.9 |
| 305X305X50 | 0.0745 | 198.00 | 90-165 | 13.8 |
| 381X381X50 | 0.122 | 325.80 | 130-265 | 23.2 |
| 432X432X50 | 0.160 | 427.20 | 210-350 | 34.5 |
| 508X508X50 | 0.227 | 606.60 | 280-465 | 43.7 |
| 585X585X50 | 0.341 | 772.20 | 370-540 | 57.3 |
